        RF SPIN

        Broadband Antenna Solutions

        H-A33-W20

        Pyramidal Horn Antenna

        Pyramidal horn antenna with the surface finish from Alodine 2040. H-A33-W20 pyramidal horn antenna is made with precision and care with the latest technology to deliver accurate and reliable antenna measurements.  The operating frequency is from 22 GHz up to 33 GHz with a flat Gain of 20 dBi. The H-A33-W20 can be supplemented with a corresponding Waveguide to Coax Adapter.

        Availability: Most products are on stock. Please contact us for more information or large quantity orders.

        Features and Specifications

        Technical Performance

        • Wide bandwidth
        • Low return loss

        Design and Surface Treatment

        • Corrosion-resistant coating

        Manufacturing Technology

        • Manufactured using a high grade aluminum alloy
        • Extremely durable

        Product Packaging Includes

        • Antenna

        Product Parameters

        Product identification

        • Product Name H-A33-W20
        • Product Category Pyramidal Horn Antenna

        Electrical specifications

        • Frequency Range 22 GHz – 33 GHz
        • VSWR (max.) 1.14
        • VSWR (avg.) 1.1
        • Waveguide Size WR34
        • Waveguide Flange UG-1530/U

        Physical specifications

        • Width 62 mm (2.441 in)
        • Height 100 mm (3.937 in)
        • Depth 45 mm (1.772 in)
        • Weight 0.105 kg (0.231 lb)

        Operating conditions

        • Rated Temperature Range 0°C – +50°C
        • Storage Temperature Range -20°C – +70°C

        Parameters and Performance

        Typical parameters

        VSWR

        H-A33-W20 - VSWR

        Gain

        H-A33-W20 - Gain

        Antenna Factor

        H-A33-W20 - Antenna Factor

        Beamwidth

        Packaging and Accessories

        What's in a box

        • H-A33-W20 Antenna

        Accessories

        • Standard mounting flange
