        RF SPIN

        Broadband Antenna Solutions

        New model 2025

        LPP0380

        Log-Periodic Antenna

        online calibration protocol & dataset available

        The LPP0380 antenna offers a broad frequency range of 300 MHz to 8 GHz, making it ideal for EMC/EMI measurements with high field strength. Its compact, lightweight design ensures easy handling, while its robust construction guarantees durability in demanding environments. A perfect balance of precision and reliability for your testing needs.

        Frequency Range
        300 MHz – 8 GHz
        Connector
        N (female)
        Polarization
        Linear
        Made on demand
        14 days to manufacture

        Features and Specifications

        Technical Performance

        • Wide bandwidth
        • Low return loss
        • Individual calibration
        • Suitable for EMC/EMI applications

        Design and Surface Treatment

        • Corrosion-resistant coating

        Manufacturing Technology

        • Manufactured using a high grade aluminum alloy
        • Extremely durable
        • High quality N type coaxial connector

        Product Packaging Includes

        • Linear polarized log-periodic antenna for receiving and transmitting applications

        Product Parameters

        Product identification

        • Product Name LPP0380
        • Product Category Log-Periodic Antenna

        Electrical specifications

        • Frequency Range 300 MHz – 8 GHz
        • Connector N (female)
        • Polarization Linear

        Physical specifications

        • Width 590 mm (23.228 in)
        • Height 49 mm (1.929 in)
        • Depth 819 mm (32.244 in)

        Operating conditions

        • Rated Temperature Range 0°C – +50°C
        • Storage Temperature Range -20°C – +70°C

        Parameters and Performance

        Typical parameters

        VSWR

        LPP0380 - VSWR

        Gain

        LPP0380 - Gain

        Antenna Factor

        LPP0380 - Antenna Factor

        Packaging and Accessories

        What's in a box

        • LPP0380 Antenna
        • Factory calibration certificate
        • Full calibration report of each antenna
        • QR code accessing online portal
        • Calibration test dataset (available online)

        Accessories

        • Standard mounting flange
        • Factory calibration report

        Custom services

        • Custom mounting solutions
        • Custom calibration data
