FHA90G9 Special Purpose Antenna | 8.2 GHz – 12.4 GHz
This precision-engineered feed horn antenna provides reliable performance across the X-band frequency range from 8.2 to 12.4 GHz. Designed for use in antenna measurements, reflectors, and communication systems, it offers stable radiation characteristics and excellent return loss.
Frequency Range
8.2 GHz – 12.4 GHz
VSWR (avg.)
1.2
Gain
10 – 11 dBi
Impedance
50 Ohm
Connector
SMA (female)
Power (CW / Peak)
100 W / 170 W
Polarization
Linear
Select files to be sent by e-mail
Product Highlights
Product Parameters
Product identification
- Product Name FHA90G9
- Product Category Special Purpose Antenna
Electrical specifications
- Frequency Range 8.2 GHz – 12.4 GHz
- VSWR (max.) 1.5
- VSWR (avg.) 1.2
- Impedance 50 Ohm
- Connector SMA (female)
- Power (CW / Peak) 100 W / 170 W
- Antenna Factor 38 – 42 dB/m
- Polarization Linear
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Physical specifications
- Width 115 mm (4.528 in)
- Height 285 mm (11.220 in)
- Depth 115 mm (4.528 in)
- Weight 0.705 kg (1.554 lb)
Parameters and Performance
Typical parameters
VSWR
Gain
Antenna Factor
Beamwidth
Packaging and Accessories
Accessories
- Standard mounting flange
