SH38-07R Circularly Single Polarized Antenna | 37.5 GHz – 39 GHz
SH38-07R delivers consistent gain across its operating range for optimal signal strength. The low VSWR ensures efficient transmission, while the compact design allows for seamless integration into your system.
Frequency Range
37.5 GHz – 39 GHz
VSWR (avg.)
1.2
Gain
7.3 – 7.6 dBi
Impedance
50 Ohm
Power (CW / Peak)
15 W / 25 W
Made on demand
Lead time 4-8 weeks
Need more information?
Select files to by sent by e-mail
Product Highlights
Product Parameters
Product identification
- Product Name SH38-07R
- Product Category Circularly Single Polarized Antenna
Electrical specifications
- Frequency Range 37.5 GHz – 39 GHz
- VSWR (max.) 1.6
- VSWR (avg.) 1.2
- Impedance 50 Ohm
- Power (CW / Peak) 15 W / 25 W
- Antenna Factor 54 – 55 dB/m
Physical specifications
- Width 26 mm (1.024 in)
- Height 29.6 mm (1.165 in)
- Depth 22 mm (0.866 in)
- Weight 0.015 kg (0.033 lb)
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Parameters and Performance
Typical parameters
VSWR
Gain
Antenna Factor
Beamwidth
Port A, E plane
Port A, H plane
Port B, E plane
Port B, H plane
