FHA75G9 Special Purpose Antenna | 10 GHz – 15 GHz
This high-performance feed horn antenna operates across the 10 GHz to 15 GHz frequency range, delivering stable radiation characteristics and low return loss. It is ideal for use as a feed in reflector systems, antenna measurements, and broadband communication applications.
Frequency Range
10 GHz – 15 GHz
VSWR (avg.)
1.2
Gain
9 – 10 dBi
Impedance
50 Ohm
Connector
SMA (female)
Power (CW / Peak)
75 W / 150 W
Polarization
Linear
Made on demand
Lead time 4-8 weeks
Need more information?
Select files to by sent by e-mail
Product Highlights
Product Parameters
Product identification
- Product Name FHA75G9
- Product Category Special Purpose Antenna
Electrical specifications
- Frequency Range 10 GHz – 15 GHz
- VSWR (max.) 1.5
- VSWR (avg.) 1.2
- Impedance 50 Ohm
- Connector SMA (female)
- Power (CW / Peak) 75 W / 150 W
- Antenna Factor 41 – 44 dB/m
- Polarization Linear
Physical specifications
- Width 115 mm (4.528 in)
- Height 285 mm (11.220 in)
- Depth 115 mm (4.528 in)
- Weight 0.676 kg (1.490 lb)
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Parameters and Performance
Typical parameters
VSWR
Gain
Antenna Factor
Beamwidth
Packaging and Accessories
Accessories
- Standard mounting flange
