FHA28G9 Special Purpose Antenna | 26.5 GHz – 40 GHz
This high-precision feed horn antenna operates from 26.5 to 40 GHz, delivering stable radiation patterns and low return loss across the entire Ka-band. It is well-suited for reflector feeds, antenna characterization, and broadband communication systems requiring reliable high-frequency performance.
Frequency Range
26.5 GHz – 40 GHz
VSWR (avg.)
1.3
Gain
7 – 9 dBi
Impedance
50 Ohm
Connector
K (female)
Power (CW / Peak)
15 W / 30 W
Polarization
Linear
Made on demand
Lead time 4-8 weeks
Need more information?
Select files to by sent by e-mail
Product Highlights
Product Parameters
Product identification
- Product Name FHA28G9
- Product Category Special Purpose Antenna
Electrical specifications
- Frequency Range 26.5 GHz – 40 GHz
- VSWR (max.) 1.8
- VSWR (avg.) 1.3
- Impedance 50 Ohm
- Connector K (female)
- Power (CW / Peak) 15 W / 30 W
- Antenna Factor 50 – 55 dB/m
- Polarization Linear
Physical specifications
- Width 115 mm (4.528 in)
- Height 285 mm (11.220 in)
- Depth 115 mm (4.528 in)
- Weight 0.437 kg (0.963 lb)
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Parameters and Performance
Typical parameters
VSWR
Gain
Antenna Factor
Beamwidth
Packaging and Accessories
Accessories
- Standard mounting flange
