BIA300-10 Biconical Antenna | 30 MHz – 300 MHz
This professional-grade biconical antenna provides continuous broadband coverage from 30 MHz to 300 MHz, eliminating the need for multiple antenna changes during testing. It features an integrated precision balun that ensures excellent impedance matching and highly stable radiation patterns across the entire frequency range. Rugged yet lightweight, it is an ideal solution for radiated emissions testing, immunity measurements, and general spectrum monitoring.
Frequency Range
30 MHz – 300 MHz
VSWR (avg.)
2
Gain
-12 – 5 dBi
Impedance
50 Ohm
Connector
N (female)
Power (CW / Peak)
10 W / 20 W
Polarization
Linear
Made on demand
Lead time 4-8 weeks
Need more information?
-
Datasheet
Select files to by sent by e-mail
Product Highlights
Key Features
- Premium broadband antenna
- Precision-tuned for optimal performance
- Designed for versatile applications
Performance & Versatility
- Enhanced signal strength
Manufacturing & Technologies
- In-house production
- High-grade aluminum alloy
Product Parameters
Product identification
- Product Name BIA300-10
- Product Category Biconical Antenna
Electrical specifications
- Frequency Range 30 MHz – 300 MHz
- VSWR (max.) 15
- VSWR (avg.) 2
- Impedance 50 Ohm
- Connector N (female)
- Power (CW / Peak) 10 W / 20 W
- Antenna Factor 5 – 28 dB/m
- Polarization Linear
Physical specifications
- Width 1370 mm (53.937 in)
- Height 580 mm (22.835 in)
- Depth 580 mm (22.835 in)
- Weight 3.5 kg (7.716 lb)
Operating conditions
- Rated Temperature Range 0°C – +50°C
- Storage Temperature Range -20°C – +70°C
Mechanical Drawings
Antenna
Parameters and Performance
Typical parameters
VSWR
Gain
Antenna Factor
Packaging and Accessories
What's in a box
- BIA300-10 Antenna
Accessories
- Standard mounting flange
